FlySky FS-iA6 / iA6B / iA10B / X6B Receiver
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 1
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 2
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 3
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 4
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 5
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 6
BrandFlySkyModelFS-iA6 / iA6B / iA10B / X6B

FlySky FS-iA6 / iA6B / iA10B / X6B Receiver

Price range: $18.33 through $26.33

StockIn stock - select an option
WarehouseChina Warehouse

Four FlySky AFHDS 2A receiver options for compatible aircraft and multirotor transmitters. Select FS-iA6, FS-iA6B, FS-iA10B, or FS-X6B.

Save Part
Delivery informationShipping service, cost, and delivery estimate depend on the destination.
Shipping details
  • Fitment supportSend a part photo before ordering.Check fitment
  • Returns & warrantyCoverage follows the published policy.View policy
  • Order trackingTracking is provided after dispatch.Track order
Key specifications
Voltage sensor port
External power sensor (1S-4S connector) +0 to +18V.
Dimensions
40.4 x 21.1 x 7.35 mm
Dimension
47 x 26.2 x 15mm
Weight
6.4g / 5g / 0.18ounce / 14.9g
Frequency Range
2.4-2 .48 GHz / 2.4055--2.475GHZ
Payment supportSupported payment platforms. Availability is confirmed at checkout.
Share

Product Overview

FlySky FS-iA6 2.4G 6CH AFHDS Receiver

FLYSKY FS-X6B 2.4G 6CH IBUS PPM PWM Receiver

Fit for FS-i10,FS-i8,FS-i6,FS-i6s,FS-i6x,FS-i4,FS-i4x ect.FS series rc transmitter.NOT INCLUDED THE REMOTE CONTROL

It is a 6 channel two-way receiver designed for multi-rotor aircraft

Product Images & Diagrams

FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 1
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 2
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 3
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 4
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 5
FlySky FS-iA6 / iA6B / iA10B / X6B Receiver detail image 6

Key Product Details

Dimensions
40.4 x 21.1 x 7.35 mm
Dimension
47 x 26.2 x 15mm
Weight
6.4g
Material
Composite Material
Brand Name
Flysky
Item Name
FS-iA6 receiver

Technical Specifications

BrandFlySky
Product ModelFS-iA6 / iA6B / iA10B / X6B
Product SystemRadio Receiver
Channels6
Frequency Range2.4-2 .48 GHz
Frequency Channels140
Transmitting Powernot more than 20dBm
Receiver Sensitivity-105dBm
2.4G modesAutomatic frequency second generation digital systems
EncodingGFSK
Weight6.4g
Input Power4.0-6 .5 V DC
Dimensions40.4 x 21.1 x 7.35 mm
ColorBlack
i-BUS InterfaceNo
Data Acquisition InterfaceNo
UsageSuitable for RC Airplane / glider / helicopter
Compatible TransmitterFlysky FS-i10,FS-i6,FS-i4,FS-GT2F,FS-GT2E,FS-GT2B
Size37*22*7mm/1.4*0.9*0.3inches
Weight5g / 0.18ounce
PWM signal portGND, VCC. Outputs channels 1-6 PWM.
PPM signal portOutputs standard PPM signal.
BUS signal portOutputs i-Bus signal,up to 18 channels.
Voltage sensor portExternal power sensor (1S-4S connector) +0 to +18V.
Channel6
Frequency Range2.4055--2.475GHZ
Transmitting Power≤ 20dBm
RF Receiver Sensitivity-105dbm
2.4G ModeThe second generation of an enhanced version of the automatic FM digital system
Antenna Length26mm * 2 (dual antenna)
Input Power4.0-6.5V DC
Dimension47 x 26.2 x 15mm
Weight14.9g
i-Bus InterfaceYes
Data Acquisition InterfaceYes
Model TypeAirplane / Glider / Helicopter
Compatible TransmitterCompatible with FS-i4,FS-i6,FS-i10,FS-GT2E,FS-GT2G
Available OptionsFS-iA10B, FS-iA6, FS-iA6B, FS-X6B

Technical Notes

  • Ports:
  • Binding:
  • To prepare the transmitter for binding information refer to your transmitter's user manual.
  • Power on the receiver while holding the bind button. If the receiver's LED is flashing this means it has entered bind mode. After the successfully binding, the transmitter will automatically return to the previous menu. If binding is successful the receiver's LED will stop flashing a remain solid.
  • Check if all the model and receiver work as expected. If anything does not work as expected, restart this procedure from the beginning.
  • Compatible Transmitters:
  • The FS-X6B receiver is compatible with all AFHDS 2A Transmitters,for example FS-i10,FS-i8,FS-i6,FS-i6S,FS-i6X,FS-i4,FS-i4X
  • Packing Includes:
  • 1* FS X6B Receiver
  • 4* cable

Compatibility & Shipping

Check fitment by photo
Ships From: China Warehouse
Processing Time: 1-3 business days

Model Reference

These model references come from supplier data and are not independently verified. Match the connector, voltage, mounting size, and selected option before ordering.

Brand Model System Status
FlySky FS-i6 / i6X / i6S / i10 / TH9A Radio Receiver Verify before ordering
